Ultimate Oil Separation • 2007–2022 1VD-FTV 4.5L V8 • PV614DPK
🛡️ Protect Your V8 — Keep It Breathing Clean 🛡️
Prevents oil vapour buildup in your intake system, keeping your legendary 200 Series V8 running strong. Essential protection for the hardworking 1VD-FTV.
✅ Engineered specifically for 200 Series V8 crankcase system
How It Works: The ProVent intercepts crankcase gases before they reach the intake. Oil is separated and collected or returned to the sump (optional), while clean air is recirculated to the intake system. This maintains airflow efficiency and protects vital components from contamination.
Key Features:
💡 Why This Matters: Modern diesel engines with EGR systems are prone to intake contamination. Oil vapour from blow-by mixes with carbon from the exhaust, creating thick sludge that blocks manifolds, fouls sensors, and reduces performance. Over time, this causes higher fuel consumption, reduced power, and costly repairs. The ProVent prevents this buildup, saving on long-term maintenance costs and keeping your legendary V8 healthy.
EGR systems create a perfect storm for contamination. The 200 Series V8 is legendary for reliability, but its EGR system creates a challenge. Oil vapour from blow-by mixes with sooty EGR gases, creating thick sludge that coats everything in your intake system.
Benefits:
💡 The EGR Problem: EGR (Exhaust Gas Recirculation) systems are great for emissions, but they introduce sooty exhaust gases into your intake. When this mixes with oil vapour from blow-by, it creates a sticky, thick sludge that coats intercoolers, manifolds, and intake valves. The ProVent stops the oil vapour before it can mix with EGR gases, preventing this expensive problem.
ProVent Ultimate Catch Can:
Performance:
✅ Vehicle-specific components for direct fitment on 200 Series V8
Recommended: Competent qualified mechanic
DIY Time: 2–3 hours
Installation Notes:
Important: Detailed installation guide included. Can be installed independently or as part of a comprehensive protection package. Professional installation recommended if not experienced with automotive work.
Maintenance Schedule:
💡 Pro Tip: The 200 Series is built for serious touring. Regular ProVent maintenance takes just minutes and prevents the expensive intake system cleaning that EGR-equipped diesels often require. Keep your legendary V8 breathing clean for the long haul.
Q: Will this void my Toyota warranty?
A: No. This kit does NOT void your factory warranty. Backed by Australian standards and supported by the AAAA Genuine Parts Warranty Facts. Aftermarket protection devices don't void warranty under Australian Consumer Law.
Q: Why does the 200 Series V8 need a catch can?
A: The 1VD-FTV V8 uses an EGR system that recirculates sooty exhaust gases into the intake. When oil vapour from blow-by mixes with these sooty gases, it creates thick sludge that coats your intercooler, manifolds, and intake valves. A catch can prevents the oil vapour from mixing with EGR gases, stopping this expensive problem.
Q: What is EGR sludge and why is it a problem?
A: EGR (Exhaust Gas Recirculation) introduces sooty exhaust gases into your intake for emissions control. When this soot mixes with oil vapour from crankcase blow-by, it creates a sticky, tar-like sludge that builds up in intercoolers, intake manifolds, and on intake valves. This restricts airflow, reduces power, increases fuel consumption, and eventually requires expensive cleaning or component replacement.
Q: How does the ProVent prevent this sludge?
A: By capturing 98% of oil vapour BEFORE it enters the intake system, the ProVent prevents the oil from mixing with EGR soot. Clean air (without oil) can handle the soot much better—it doesn't stick and build up like oily sludge does.
Q: How often do I need to drain the catch can?
A: Check every 5,000–10,000 km. Drain frequency depends on your driving conditions and engine condition. The 200 Series V8 typically collects a moderate amount of oil. If you've configured the optional sump return line, oil automatically recirculates and you rarely need to drain manually.
Q: Does the ProVent return oil to the sump automatically?
A: The kit includes components for an optional sump return line. You can configure it to either: (a) collect oil in the catch can for periodic draining, or (b) return clean oil back to the sump automatically for closed-loop operation. Your choice based on preference.
Q: Can I install this myself?
A: If you're mechanically competent and comfortable working with hoses and brackets, yes. Most DIYers complete installation in 2-3 hours using the included 200 Series-specific brackets. Otherwise, any qualified mechanic can handle it. A detailed installation guide is included.
Q: Will this improve performance or fuel economy?
A: While not primarily designed for performance gains, keeping your intake system clean helps maintain optimal engine efficiency. By preventing sludge buildup, the ProVent helps your 200 maintain factory performance levels over time—something that becomes increasingly important as the vehicle ages.
Q: How does this affect crankcase pressure?
A: The ProVent includes integrated crankcase pressure regulation. This maintains optimal crankcase pressure, reducing blow-by risk and preventing excessive pressure that can cause oil leaks. Proper pressure regulation is critical for engine longevity.
Q: What happens to my turbocharger without a catch can?
A: Oil vapour coats the turbocharger compressor wheel with a sticky film. Over time, this reduces efficiency and can cause imbalance. In severe cases, it can lead to turbo failure. The ProVent keeps the compressor wheel clean, extending turbo life.
Q: How often should I replace the filter element?
A: Replace the MANN+HUMMEL filter element every 40,000 km. Replacement elements are readily available. This is a simple maintenance item that ensures continued high performance.
Q: Is this suitable for heavy towing and touring?
A: Absolutely essential for serious touring and towing. The 200 Series is a workhorse that often operates under sustained load. This increases blow-by and makes oil vapour separation even more critical. The ProVent is built for exactly this kind of hard work.
Q: What is MANN+HUMMEL media?
A: MANN+HUMMEL is a world-leading manufacturer of filtration systems, supplying OEM filters to major automotive manufacturers. Their filtration media is engineered for maximum efficiency and longevity—the same quality used in premium European vehicles.
Q: Can I use this with other protection systems?
A: Yes! Many 200 Series owners run both a fuel pre-filter (or post-filter) AND a ProVent catch can for comprehensive protection. They protect different systems—fuel filtration protects your injectors, while the ProVent protects your intake system.
Q: How much oil typically collects?
A: The 200 Series V8 typically collects moderate amounts—perhaps 100-200ml between services depending on driving conditions and engine condition. Higher mileage engines or those used for towing may collect more.
Q: What about intercooler cleaning?
A: By preventing oil vapour from entering the intake, the ProVent dramatically reduces intercooler fouling. Many 200 Series owners without catch cans find their intercoolers eventually need professional cleaning—an expensive service. The ProVent prevents this problem.
Q: Is this built for Australian conditions?
A: Yes! Direction-Plus™ engineering means this kit is specifically designed for Australian conditions—extreme heat, dust, and the serious touring and towing the 200 Series is famous for. Built for the way Aussies actually use their LandCruisers.
Q: Does this fit both early and late 200 Series models?
A: Yes, this kit fits all 2007–2022 200 Series models with the 1VD-FTV 4.5L V8. The crankcase ventilation system remained consistent across the production run.
Protect Your 200 Series V8
Upgrade your 200 Series and drive with peace of mind
Essential protection against EGR sludge and intake contamination
👉 ADD TO CART NOW 👈
