SAK Turbo

4JJ3 44mm Turbo Upgrade - SAK Turbo

4JJ3 44mm Turbo Upgrade - SAK Turbo

Regular price $2,567.00 NZD
Regular price $2,933.00 NZD Sale price $2,567.00 NZD
Sale Sold out

Taxes excluded. Shipping calculated at checkout.

Quantity
Ships Same or Next Business Day
Secure Checkout
VISA Pay Pay
4JJ3 44mm Turbo Upgrade: SAK Turbo

44mm Gated | Stock Manifold Bolt-On | 240 to 280 RWHP | Isuzu D-MAX, MU-X and Mazda BT-50 (2020 on)

SAK Turbo44mm 6/6 BladeExternal Gate ActuatorStock Manifold Bolt-OnAfterpay, Humm, Klarna, ZipFree Express Shipping AU

The SAK 44mm is the proven 4JJ3 turbo upgrade for D-MAX, MU-X and BT-50 owners chasing strong mid-range torque without giving up response. It bolts straight to the factory 4JJ3 exhaust manifold, runs an external wastegate actuator, and supports tuned street and touring builds well beyond the stock unit.

Quick spool, strong mid-range. The response-focused option for touring, towing and tuned daily builds in the 240 to 280 rwhp range.


What Is Included
  • SAK 44mm turbocharger
  • Wastegate actuator
  • Oil feed line with banjos and copper washers
  • Oil drain fitting with hose and clamps
  • Gasket set

Specifications and Power
Spec Value
Engine Isuzu 4JJ3-TCX 3.0L turbo diesel
Compressor 44mm, 6/6 blade
Turbine 11 blade
Flange Stock 4JJ3 manifold pattern, direct bolt-on
Rear housing Size 12 standard (small and large A/R available to order)
Control External wastegate actuator (gated)
Boost capability Approx 30 to 40 psi, build and tune dependent
Power range Approx 240 to 280 rwhp with supporting mods and appropriate tuning

Vehicle Fitment
Vehicle Engine Years
Isuzu D-MAX 4JJ3-TCX 2020 on
Isuzu MU-X 4JJ3-TCX 2021 on
Mazda BT-50 4JJ3-TCX 2020 on

Mounts directly to the factory exhaust manifold, no manifold change required. Running a 4JJ1? The 44mm can be adapted to DPF 4JJ1 models with a custom exhaust. Message us with your VIN and we will confirm the right option.


Fitting Notes
  • The factory turbo oil drain hose must be cut to length and joined to the supplied drain pipe.
  • A professional ECU remap is required to set safe boost, rail pressure and fuelling, and to actually realise the gains.
  • DPF-equipped vehicles may require custom dump or exhaust adaptations.

Ensure all modifications comply with your local laws. On-road emissions tampering may be illegal. Intended for off-road and competition use where applicable.


Recommended Supporting Mods

Upgraded intercooler, high-flow intake and exhaust, and 4JJ3 +30 injectors at the upper end of the power range, plus a professional remap.

Which turbo suits my build? Chasing bigger top-end numbers? The Flex F55 turbo for 4JJ3 runs larger 48.5mm wheels and supports up to around 300 rwhp on well-supported builds. Not sure which way to go? Send us your power goal and mod list.


Shipping and Payment
  • Afterpay, Humm, Klarna and Zip available
  • Free express shipping Australia-wide with tracked dispatch
  • Warranty and returns: see our refund policy

Frequently Asked Questions

Will the SAK 44mm bolt straight onto a stock 4JJ3?
Yes. It is designed for the stock 4JJ3 manifold pattern and reuses most factory locations. Minor oil feed, drain and intake adjustments may be needed depending on your setup.

Do I need an ECU tune after a 4JJ3 turbo upgrade?
Yes. A professional remap is required to set safe boost, rail pressure and fuelling targets. Without a tune you will not see the gains and you risk unsafe EGTs.

How much power does the SAK 44mm support?
Typical tuned builds land around 240 to 280 rwhp with supporting mods such as an upgraded intercooler, high-flow intake and exhaust, and appropriate injectors at the upper end.

What boost should I run?
Typical tuned setups see around 30 to 35 psi. Targets up to about 40 psi are possible on well-supported builds. Follow your tuner's guidance.

Does this suit 4JJ1 models?
This listing targets the 4JJ3 (2020 on). It can be adapted to DPF 4JJ1 models with a custom exhaust. Message us with your VIN for the correct 4JJ1 options.

240 to 280 RWHP. Quick Spool. Stock Manifold.

SAK 44mm 4JJ3 turbo upgrade for D-MAX, MU-X and BT-50. Tune required. Free express shipping Australia-wide.

Common Rail Cowboys is not affiliated with Isuzu Motors, Mazda Motor Corporation or SAK. Installation should be carried out by a competent person and professional tuning is required. Fitment to your vehicle is the buyer's responsibility. Performance modifications may affect your vehicle's warranty, insurance and road compliance. Power and boost figures depend on supporting mods, fuel quality, tune and dyno.
