NPC 750Nm Super Heavy Duty Clutch Kit – Toyota Hilux N70 (2005–2015)
Part No: NPC7678-1D
🚚 Free Express AU 💳 Afterpay • Humm • Klarna • Zip 💪 750Nm Rated
Upgrade your Hilux the right way – NPC's NPC7678-1D Super Heavy Duty 750Nm clutch & billet flywheel package is built for the 1KD-FTV 3.0L D-4D. This is NPC's top organic tier for the N70 – aimed at heavily modified, tuned and hard-worked builds that need maximum holding power with proper street manners.
🧩 Overview
- Torque capacity: 750Nm (NPC measured dyno figure at the wheels) • Power: ~300HP (setup-dependent)
- NPC "Super Heavy Duty" organic 275mm disc (275×29×21T) on a modified Exedy HD pressure plate
- NPC CNC-machined billet steel flywheel – single-mass, stable, serviceable
- 20–45% more clamp vs OEM for serious torque-holding
- Heavier pedal feel than standard – firmer underfoot than the factory clutch, but still streetable (see FAQs)
- Chasing more headroom? Step up to the 850Nm Ultra Heavy Duty kit for +50 injector and big-turbo builds pushing past 750Nm
🔧 Suits / Compatibility
- Toyota Hilux N70 – KUN16 / KUN26 – 2005 - 2015 – 1KD-FTV 3.0L – manual transmission
- Suits both early 260mm and late 275mm flywheel applications (billet flywheel supplied)
✨ Features
- NPC Super Heavy Duty spec – high-clamp Exedy-based cover modified for big 1KD torque
- 275mm organic plate (275×29×21T) – strong bite with progressive engagement
- NPC billet steel flywheel – consistent friction surface under heat
- Built for tuned 4x4s, big-power towing rigs & heavily modified builds
📦 What's Included
- NPC Super Heavy Duty organic clutch disc (Exedy base)
- NPC-modified HD pressure plate
- 275mm NPC billet steel flywheel
- Throwout bearing
- Spigot bearing
- Clutch alignment tool
🛠 Install Notes
- Recommended upgrade: NPC braided clutch hose (damper delete) – sharper pedal & reliability
- The supplied NPC billet flywheel comes machined and ready to fit – no machining required. If reusing an existing flywheel instead, it must be machined before the new clutch is fitted or NPC warranty is void
- Torque to spec, align properly, and bed in for 1,000km of gentle around-town driving (it's the gear changes that bed it in)
- Inspect fork pivot, slave cylinder & rear main while you're in there
⚠ Important Notes
- Pedal feel: expect a noticeably firmer pedal than stock – this is normal for a high-clamp upgraded cover
- Rated capacity assumes a healthy drivetrain and correct tune
- Some setups may exhibit light gear rattle at idle with a single-mass billet flywheel
- If fitting the braided line / damper delete, NPC note this can introduce a slight pedal pulsation (normally dampened by the factory accumulator); this is not covered under warranty
💳 Payment & 🚚 Shipping
- Afterpay • Humm • Klarna • Zip available
- Free Express Depot Shipping Australia-Wide
❓ FAQs
Will the pedal feel heavier than standard?
Yes. This is a high-clamp Super Heavy Duty cover, so the pedal is noticeably firmer than the factory clutch. It's still comfortable enough for daily and around-town driving – just expect more weight underfoot than stock. A braided line / damper delete sharpens the feel further.
Is the flywheel dual-mass or single-mass?
Single-mass billet steel flywheel – stable under heat and serviceable. The supplied NPC billet flywheel comes machined and ready to fit – no machining required before installation.
Is it good for towing?
Yes. The higher clamp and billet flywheel make it ideal for towing, touring and tuned big-power builds, provided it's installed and bedded in correctly.
How is this different to the 850Nm kit?
The 850Nm Ultra Heavy Duty kit (NPC7678-1D/1) is the next tier up – a higher-clamp plate spec for builds beyond 750Nm, typically +50 injectors with a big turbo, or heavy towing on serious power. Same 275mm organic style and billet flywheel; expect a slightly firmer pedal again. If your build makes over ~300HP at the wheels or you tow heavy on big power, step up to the 850.
Do I really need the braided line?
Strongly recommended. It removes the factory damper, improves pedal feel and reduces common hydraulic issues.
How long is the warranty?
12 months / 20,000km NPC warranty (conditions apply – kit must be fitted to NPC's standard; if reusing an existing flywheel rather than the supplied billet unit, it must be machined).
